Multi-axis rotary head frame
Up to 4 different types of main axes can be configured on the same turret, meeting high coaxiality and high cylindricity requirements. The turret drive can be adapted to worm gear structure or torque motor structure, and can accommodate different taper and seconds.

2. Configurable tool magazine grinding wheel exchange
The machine tool becomes more flexible, better demonstrating its comprehensive functions.

3. Excellent height travel
Height travel: 1400mm

4. Main shaft grinding rod depth
Multiple different diameters ranging from 160mm to 220mm and lengths of 550mm can be configured for the grinding main shaft.

5. Immersion-based deep processing (non-intensive processing)
Based on the above 3 and 4, the depth can reach 600 - 650 mm.

6. The high torque and high power of the grinding spindle
Power ranging from 25 to 45 KW, while ensuring a torque of 100 to 130 Nm, and the spindle achieves constant torque output at low speeds.

7. According to ISO230-2 standards, the motion accuracy is 4 micrometers for P and 2 micrometers for Pa.
This is superior to the performance of manufacturers with 8 micrometers for P and 4 micrometers for Pa.

8. With high-precision hardware configuration and adjustment, it ensures the reliability of high-precision interpolation grinding.
In addition to the conventional grinding of disc and cylindrical parts, the combined vertical-horizontal grinding spindle configuration and high-precision interpolation grinding can meet the processing requirements for eccentric holes, cycloidal contours, arc-end teeth, aviation blades and other special-shaped parts and complex contours.

9. The friendly human-machine interface and modularized customization programs enhance the efficiency of programming the processing flow.
Customized programming and processing interface, providing teaching-based process parameter settings and parameter-guided programming for various conventional and unconventional grinding applications. Through the human-machine dialogue parameter input method, it realizes the generation and invocation of background variable programs, and provides a background program database customized for customers and products, effectively reducing the error rate and improving production efficiency.
Backup of processing cycle and processing parameter change records.
For the module programs and functions for online measurement of various types of parts.
